A professional advanced breakout box for invehicle diagnostics / bench ECU testing, supporting both 12V / 24V systems.

More than just a basic breakout box - it exposes every OBD-II pin, monitors live voltages (true RMS), provides optional CAN termination, and supports safe, fast hookup of other diagnostic devices.

Key features:

• Universal compatibility: Works seamlessly with both 12V and 24V OBDII systems.
• VRMS Voltage Monitoring In Real Time: LCD displays true RMS voltage on all 16 OBDII pins. Visual feedback shows dynamic signals (green background), and immediately alerts for power / ground issues (pins 4 / 5 / 16)
• Built-In CAN Termination Switch: Applies a 120 resistance across the CAN pair to compensate for missing termination during single-ECU or small bench networks, improving signal integrity and reducing reflections.
• Voltage Protection & Alarm System: Features automatic audible alarms for high/low voltage deviations and reverse polarity protection. Supports a maximum load current of 2A.

Professional quality multimeter with oscilloscope functions

Fast A/D converting sampling time, built in data logging, and trend capture.

Bluetooth enabled, with App.

IP67 rated.

• 20MHz / 50MS/s bandwidth / real time sampling rate
• 320 x 240 px TFT colour LCD display
• CATIII 1000V / CATIV 600V
• Rechargeable battery
